Week 6 Lab: Forecasting National Park Visitation

Forecasting is about using patterns in past data to form a transparent, testable prediction about the future. In this lab, you will forecast monthly recreation visits to a U.S. National Park.

Each person will:

  1. Decompose the time series into trend, seasonal, and remainder components using STL.
  2. Forecast the seasonally adjusted series with a simple benchmark method.

This workflow is called forecasting with decomposition and is emphasized in Forecasting: Principles and Practice (3rd ed.) (FPP3) (Hyndman and Athanasopoulos 2018).

Learning Objectives

By the end of the lab, you will be able to:

  • Convert monthly data into a tsibble (tidy time series)
  • Use STL decomposition to separate a series into interpretable components
  • Explain what seasonal adjustment does (and why it can help forecasting)
  • Build a simple decomposition-based forecast
  • Evaluate forecast accuracy using a train/test split
  • Compare forecasts to a strong benchmark (seasonal naive)

Lab Notebook

Open up a word processing document (e.g., Google Doc, Word, or plain text) to serve as your lab notebook. Use this to respond to questions, document decisions, and reflect on the process. You should also comment your R script thoroughly to explain your code and rationale for each step.

Section 0: Setup

Download data

We will download data on monthly National Park visitation from the Integrated Resource Management Applications (IRMA) Portal

Placeholder for video walkthrough of data download process.

Preliminaries

  1. Create a folder called lab_06.
  2. Create a new R script called lab_06.R in that folder.
  3. Write a brief comment at the top describing the purpose of the script and your name.
  4. Load required libraries at the top:
# install.packages("fpp3")  # only if you don't have it
library(fpp3)              # loads tsibble, feasts, fable, etc.
library(tidyverse)

The fpp3 package loads the toolchain used in the textbook FPP3.

Load the Arches monthly visitation data

arches_raw <- read_csv("arches.csv")

glimpse(arches_raw)

The key outcome for this lab is RecreationVisits, monthly recreation visits (this is the standard visitation measure in NPS visitor use stats).

Question 1 (7%): What is the unit of observation in arches_raw? (What does one row represent?) Answer in your notebook.

Section 1: Make a time series object

Time series forecasting requires a clear time index.

  • Index: time variable (year-month)

First, we need to convert the raw data into a tsibble (tidy time series format). A tsibble is a data frame with special attributes that allow it to be used with time series functions in the fpp3 ecosystem. We will create a new variable for the time index using a function from the tsibble package called yearmonth().

arches <- arches_raw %>%
  mutate(ymonth = make_yearmonth(year=Year,month=Month),
         visits = RecreationVisits) %>%
  select(ymonth, visits) %>% #keep only the time index and the variable we care about
  arrange(ymonth) %>% #ensure data is in chronological order
  as_tsibble(index = ymonth) #convert to tsibble with ymonth as the index

Plot the raw series

We use the function autoplot() from the feasts package to quickly visualize the series. autoplot recognizes the time index and creates a time series plot. Technically, autoplot is a wrapper around ggplot2 that creates a line plot of the specified variable against the time index, which means you can add layers and customize it like any ggplot.

arches %>%
  autoplot(visits)

Question 2 (8%): Describe the visitation series. Do you see:

  • long-run changes (trend / regime shifts)?
  • repeated within-year patterns (seasonality)?
  • unusual spikes (outliers)?

Answer in your notebook.

Section 2: Decomposition with STL

Time series often have multiple patterns at once. Decomposition is a way to separate these patterns into components that are easier to understand and forecast. Decomposition helps you visualize and understand your data, but it can also be used as part of a forecasting workflow (more on that later).

The idea (intuition + math)

A common way to represent a seasonal time series is an additive decomposition:

\[ y_t = T_t + S_t + R_t \]

  • \(y_t\): observed visits at month \(t\)
  • \(T_t\): trend-cycle (slow-moving component)
  • \(S_t\): seasonal component (is similar each year, but is allowed to change slowly over time)
  • \(R_t\): remainder (what’s left after removing trend + seasonality)

STL (“Seasonal and Trend decomposition using Loess”) estimates \(T_t\) and \(S_t\) using flexible smoothing, and then defines the remainder as:

\[R_t = y_t - T_t - S_t\]

STL is widely used because it is flexible and can be made robust to outliers.

Fit STL decomposition

fit_stl <- arches %>%
  model(
    STL(visits ~ trend(window = 13), robust = TRUE)
  )
  • model(STL(...)) estimates the decomposition components.
  • trend(window = 13) controls how smooth the trend is (roughly: how many months the smoother uses).
  • robust = TRUE reduces the influence of outliers on the decomposition.

Visualize the components

After fitting the model, we can extract the components and plot them to understand the patterns in the data.

components(fit_stl) %>%
  autoplot()

Question 3 (15%): Use the decomposition plot to answer:

  1. Is the seasonal component large relative to the trend and remainder? What does this say about the importance of seasonality at Arches National Park?

  2. Which months are typically highest/lowest visitation?

  3. Does the trend show multi-year growth/decline regimes?

  4. Identify at least one major “shock” period (example: abrupt drops). What might explain it?

Answer in your notebook.

Seasonally adjusted series

A “seasonally adjusted” series removes the repeating seasonal pattern so we can focus on the underlying movement:

\[ \text{SA}_t = y_t - S_t = T_t + R_t \]

This is useful because many forecasting methods work better when seasonality is removed first.

cmp <- components(fit_stl)

cmp %>%
  as_tibble() %>% #convert to tibble for easier manipulation
  select(ymonth, visits, season_adjust) %>% #subset to original and seasonally adjusted series
  pivot_longer(cols = c(visits, season_adjust), #reshape to long format for plotting
               names_to = "series",
               values_to = "value") %>%
  ggplot(aes(x = ymonth, y = value)) + #passing the long format data to ggplot
  geom_line() +
  facet_wrap(~series, ncol = 1, scales = "free_y")  #facet_wrap produces different panels for each series

Question 4 (10%): Compare the original and seasonally adjusted series. What changes? What stays the same? Answer in your notebook.

Section 4: Forecasting with decomposition

The forecasting workflow

We will forecast \(y_t\) by forecasting its parts:

  1. Decompose: \(y_t = T_t + S_t + R_t\)

  2. Forecast the seasonally adjusted series: \[\widehat{\text{SA}}_{t+h}\]

  3. Forecast the seasonal component: \[\widehat{S}_{t+h}\]

  4. Re-seasonalize to get the final forecast: \[\hat{y}_{t+h} = \widehat{\text{SA}}_{t+h} + \widehat{S}_{t+h}\]

This is the “forecasting with decomposition” workflow in Hyndman and Athanasopoulos (2018) Chapter 5.7.

Train/test split

We have covered how we will do the forecasting. We will evaluate the forecast by comparing it to actual values that we withhold from the model. We will define a “training” dataset to estimate model parameters, then assess performance on the “test” set (the set that the model has not yet seen). This is called a train/test split.

We will hold out the last 36 months to test forecasting performance.

h <- 36 #forecast horizon (months to hold out)
last_month <- max(arches$ymonth) #define the last month in the data

#Create training and test sets based on the last month and forecast horizon
train <- arches %>%
  filter(ymonth <= (last_month - h))

test <- arches %>%
  filter(ymonth > (last_month - h))

Fit a decomposition-based forecasting model

Here’s the key modeling step:

  • Decompose with STL
  • Forecast the seasonally adjusted series using ETS (error-trend-seasonal) model, which is a flexible exponential smoothing method that can capture various types of trends and seasonality. ETS is a common choice for forecasting the seasonally adjusted series because it can adapt to different patterns in the data (Hyndman and Athanasopoulos 2018).
  • Automatically reseasonalize the forecast
#Estimate the decomposition-based forecasting model
fit_dcmp <- train %>%
  model(
    stlf = decomposition_model(
      STL(visits ~ trend(window = 13), robust = TRUE),
      ETS(season_adjust)
    )
  )

#Use the model to forecast the next 36 months
fc_dcmp <- fit_dcmp %>%
  forecast(h = h)

#Plot the forecasts (with the test data visible)
forecast_plot <- fc_dcmp %>%
  autoplot(test)

#Display the plot
forecast_plot

#save the plot as "forecast_plot.png" in the current working directory
ggsave("forecast_plot.png", plot = forecast_plot, width = 5, height = 5, units = "in")

This is similar to the approach used in Hyndman and Athanasopoulos (2018) for decomposition-based forecasting examples.

Section 5: Forecast accuracy

We care about out-of-sample accuracy: how close forecasts are to reality in the held-out test period.

Common metrics:

  • MAE: mean absolute error - the average size of the errors (ignoring direction)
  • RMSE: root mean squared error - the square root of the average squared errors (penalizes large misses)
  • MAPE: mean absolute percentage error - the average size of errors relative to actual values (can be misleading when actuals are close to zero)
accuracy(fc_dcmp, test) %>% #generates a data frame of accuracy metrics by comparing forecasts to test data
  select(.model, MAE, RMSE, MAPE) #subsetting to just the metrics we care about

Question 5 (20%): Report MAE and RMSE.

  • In plain language: how good were the forecasts over the last 36 months?
  • When you look at the forecast plot, can you see any patterns in the forecast errors (too high, too low, systematic bias)?

Arches NP implemented a reservation system in 2020 that may have changed visitation patterns.

  • Do you see any evidence of this in the forecast errors?

However, they just announced that the reservation system will be removed in 2026.

  • How might you account for this in future forecasting?

Answer in your notebook.

Section 6: Compare to a simple benchmark

A model should be judged against a benchmark. A natural benchmark for monthly data is seasonal naive:

\[ \hat{y}_{t+12} = y_t \]

Meaning: “This month will look like the same month last year.” It may surprise you, but seasonal naive is often a hard forecast to beat.

We can fit a seasonal naive model using the SNAIVE() function in the fable package. The syntax of model() allows us to fit multiple models at once, so we can estimate the decomposition-based forecast and the seasonal naive benchmark in one step.

fit_bench <- train |>
  model(
    stlf = decomposition_model(
      STL(visits ~ trend(window = 13), robust = TRUE),
      ETS(season_adjust)
    ),
    snaive_bench = SNAIVE(visits ~ lag("year"))
  )

fc_bench <- fit_bench |>
  forecast(h = h)

accuracy(fc_bench, test) %>%
  select(.model, MAE, RMSE, MAPE)

Adapt the plot code above to plot the decomposition-based forecast and the seasonal naive benchmark on the same graph with the test data if you want to visualize the comparison.

Question 6 (15%): Which forecast performed better: the decomposition-based forecast or seasonal naive? Answer in your notebook.

Section 7: Replicate the process for another park

Choose another park from the IRMA portal and repeat the process. You can use the same code as a template, but make sure to adjust it for the new data (e.g., variable names, date parsing).

Question 7 (15%):

  • Describe the new park’s visitation series. How does it compare to Arches NP in terms of trend, seasonality, and shocks?
  • How did the forecasting process go for the new park? Did you encounter any new challenges?
  • How did the forecast accuracy compare to Arches NP?

Answer in your notebook.

Deliverables (10%)

Submit on Canvas:

  1. log file (lab_06.log) Use the sink-source-sink pattern. Your log should include code, output and comments explaining each step.

  2. Lab notebook with answers to Questions 1–7.

  3. One figure (exported image) showing STL decomposition plot for your chosen park

References

Hyndman, Rob J., and George Athanasopoulos. 2018. Forecasting: Principles and Practice. 3rd ed. OTexts. https://otexts.com/fpp3/.
